PRECISION JIGS
Typical Data Sheet (General Specification)
| Jig Type | Use Case | Material Options | Tolerance |
|---|---|---|---|
| Drilling Jigs | Precision hole alignment on metal parts | Tool Steel / Aluminum | ±0.01 mm |
| Inspection Fixtures | Part measurement & dimensional checks | Granite / Steel | ±0.005 mm |
| Welding Jigs | Multi-axis holding for welding setups | Cast Iron / Steel | ±0.02 mm |
| Assembly Jigs | Component alignment & fastening | Aluminum / Plastic | ±0.01 mm |
| Custom Jig Systems | Full integration with automation lines | Mixed materials | As specified |
Product Description
Our Precision Jigs are engineered to deliver superior accuracy, repeatability, and efficiency across a wide range of manufacturing and assembly applications. Whether used in CNC machining, drilling, inspection, or welding processes, our custom jigs help reduce setup time, improve alignment precision, and ensure consistent product quality.
Built with hardened tool steel, aluminum alloys, or custom composite materials, our jigs are tailored to meet industry-specific demands—ranging from electronics and automotive to aerospace and home appliance manufacturing. From standard locator jigs to complex multi-functional fixtures, we support both OEM and ODM production with full design-to-delivery services.
Every precision jig is custom-built or manufactured to ISO tolerances, ensuring optimal fitment and stable performance under high-cycle usage.
Key Features and Advantages
High Dimensional Precision: Tolerances up to ±0.005 mm for critical surfaces
Modular Designs: Easily adaptable to different workpieces and equipment
Long-Term Stability: Built from wear-resistant alloys and engineered for repeat use
Full Compatibility: Integrates seamlessly with CNC machines, CMMs, and welding benches
Reduced Setup Time: Speeds up part clamping, positioning, and alignment
Custom Engineering: We support one-off prototypes and large-scale batch production
Applications / Industry Use
Electronics Industry: PCB drilling, assembly, inspection, and workholding solutions
Automotive Industry: Engine component assembly, chassis alignment, and precision jigs for stamping and machining
Aerospace Industry: Turbine blade positioning, aircraft component assembly, and custom jigs for high-precision parts
Home Appliances: Metal housings, internal components, and assembly of consumer products
General Manufacturing: High-volume production lines requiring repeatable positioning and custom fixture design
FAQs About Precision Jigs
Yes, we offer custom jigs and one-off prototypes tailored to your specifications.
Typically 3–6 weeks depending on complexity; expedited options are available.
Absolutely. Our engineers offer fixture design review, alignment guidance, and troubleshooting for all precision jigs.
Our jigs are engineered for long-term stability, maintaining accuracy over millions of cycles.
Need customization, please contact us
